VOLTCRAFT IPC4 User Manual

9. Operation
a) Touch-sensitive control panel
Three touch-sensitive buttons are used to control and set the charger. The buttons must be gently
tapped. The buttons have the following functions:
V
“Up” cursor button
The “Up” arrow button is used to move the cursor up in the menu. It can also be used to
switch the parameter display of individual cells.
“Select” middle button
The“Select”buttonisusedtoopenthesettingsmenuandconrmtheselectionofthe
cursor buttons.
V
“Down” cursor button
The “Down” arrow button is used to move the cursor down in the menu. It can also be
used to switch the parameter display of individual cells.
b) Display elements and symbols
The occupied charging slots are displayed at the bottom or on the left hand side of the screen depending
on the position. Free charging slots are not displayed. This provides a clear visualisation. If programme
items appear greyed out in the menu , they are not available in the current programme mode.
The following symbols and information are shown on the display.
34
