22-1 Oil pump and Line
Oil Pump Bearing, Change
Timing gear and crankshaft removed
Tools:
3849639 Mounting tool
3849640 Mounting tool
1 Drive
out
the oil pump bearing section (1) located
in the cylinder block. Tap it out from inside the
crankcase.
2 Use special tool 3849639 Mounting tool for D1-13
and D1-20 engines, and 3849640 Mounting tool
for D1-30 and D2-40.
First screw the guide pin (1) for the tool into the
cylinder block.
Then put the new oil pump bearing (2) into the
tool block (3).
NOTICE! It is important that the engine block sur-
face touching the tool is clean and smooth. The
tool block must be oiled.
3 Position the tool block with the bearing in place,
using the guide pin.
Tap the bearing into place until the tool bottoms
on the cylinder head.
22-1 Oil pump and Line
100 47701798 05-2013 © AB VOLVO PENTA
