Illustrations
A lot of illustrations contains standardized symbols and colors. Please refer to the following information to reduce
misunderstandings when working on an engine / transmission using this Workshop Manual.
Illustration colors
Most illustrations have a focused component (blue)
which is fastened by a (red) bolt or such on a (light
grey) engine / transmission body.
P0015699
1 Focus
(blue)
2
Fastenings
(red)
3 Body
(light grey)
4 Background
(white)
Position
P0015623
Focus arrows pointing at object. Sometimes it con-
tains number of items, e.g. three bolts.
NOTICE! If an arrow with the text “x3” is pointing at
only one item, e.g. a bolt, it still applies to the other
two alike
items (the two other bolts) highlighted in the
illustration.
P0015627
This symbol gives a positioning number to an object,
e.g. 2, which is also mentioned in the supplied text
information.
P0015628
The symbol
to the left shows part no. of the positioned
special tool, e.g. 9991801.
The symbol on the right side is used when something
needs to be replaced by a new part / kit.
