Engine Fuel Filter Replacement
Removal
1
Clean around the fuel filter.
2 NOTE! The filter is self-draining (when the fuel
tank is located under the engine); wait a couple
of seconds before removing the filter cover and
filter.
If the fuel tank has a "higher" location:
3 Close
the cock on the return line to the tank. Place
a suitable vessel underneath the filter.
Disconnect the quick connector on the return line.
4 Remove the filter cover (1).
5 Remove the O-ring (2) and filter (3).
Installation
6 Install a new filter (3) and a new O-ring (2).
7 Install the filter cover (1) and filter.
If the fuel tank has a "higher" location:
8 Reconnect the quick connector on the return line.
Open the cock on the return line and remove the
collection vessel.
9 Purge the fuel system according to the method,
Fuel system, bleeding.
10 Warm up the engine and perform a function check
in respect of any leakages.
Maintenance
73
47711097 09-2018 © AB VOLVO PENTA
