Engine protection Group 30: Electrical system
Engine protection
Derate to engine protection map
Parameter “Yellow lamp” “Red lamp” 0% 50% 70% 100% Forced to idle Forced shutdown
after 5 sec. after 15 sec.
High coolant 98 101 101 --106 >106 >106
temperature (°C)
High boost 80 83 83 --90 >90 >90
temperature (°C)
High boost 340 350 - 350 -- >355 >355
pressure (kPa)
Low oil Limit 20<limit --20<limit - 25<limit 25<limit
pressure (kPa)
Oil pressure limit
Pressure, kPa
Engine speed, rpm
Oil pressure limit
Engine protection
Engine speed, rpm
Torque, Nm
TAD 650, 660, 750, 760 VE
