124 Graphic Display
Acknowledge Information and Stop Messages
By pressing Esc, the display with the fault
message is reset and the graphic display re-
turns to the same status as before the error
occurred. An acknowledged fault message
is shown as a symbol on the right in the
graphic display window. All types of fault
messages can be acknowledged. Acknowl-
edged but active messages are shown again
when the ignition key is turned to the start
position.
T3008852
Yellow
1
INFO telltale: The text message,
yellow
1
INFO telltale and the symbol can
be acknowledged using Esc. This warning
is acknowledged until the next time the ig-
nition key is turned to the start position.
Exceptions: The message can be shown
again if the fault is de-activated and then
becomes active again.
Example: If the engine oil temperature be-
comes too high a message is activated
automatically. The driver acknowledges this
message using Esc. If the temperature then
drops to a normal level but then becomes
too high again the warning is activated
again.
T3008860
Red
1
STOP telltale: The buzzer, text
message and the symbol can be acknowl-
edged using Esc, but are active again 10
seconds after pressing the button. The red
1
STOP telltale remains lit the whole time.
T3008861
