Graphic Display 153
Main Menu: Gauge
When the menu GAUGE has been se-
lected, you switch between the various
sub-menus with the up/down buttons.
•
TEMPERATURE, ENGINE OIL
•
TEMPERATURE, TRANSMISSION
OIL (Option)
•
VOLTMETER
Temperature, engine oil
MENU: GAUGE, TEMPERATURE EN-
GINE OIL
The engine oil temperature is shown as in
the diagram.
If the sensor data for Temperature, engine
oil is not available, the symbol is shown as
well as the text NO DATA.
T3008830
185 F
T3008830
NO
DATA
Information message
Yellow
1
INFO telltale
If the engine oil temperature becomes too
high, an information message is shown au-
tomatically with the text HIGH. At the
same time the yellow
1
INFO telltale un-
der the display lights up. Esc acknowledges
the info message.
T3008830
HIGH
210
F
T3008860
