8 Components and operator's controls
22 100_0202_cp_0005.fm
8 Components and operator's controls
Machine
Electronic starter (only certain machine types)
Item Designation Item Designation
1 Central suspension 6 Integrated driving mechanism
2 Fuel tank 7 Guide handle
3 Battery (Electronic starter) 8 Control handle
4 Recoil starter 9 Throttle lever
5 Box for fittings (Electronic starter) 10 Stopping pin (Stop) (Electronic
starter)
Item Designation Item Designation
1 Operation control lamp 4 Temperature lamp
2 Charging control lamp 5 Pre-heating lamp
3 Oil pressure control lamp 6 Ignition lock
1
2
3
4
5
10
9
8
7
6
6
4
1
2
3
5
6
