www.webasto.us
59
Webasto Product N.A., Inc.
DBW 2010/2020/300 COOLANT HEATERS
REPAIR
9.2.15
F
AN
S
HAFT
, B
EARINGS
AND
G
EARING
, E
XPLODED
V
IEW
(DBW 2010)
Figure 47:
Exploded view - fan
support assembly - DBW 2010
1
2
34
56
7
8
9
1
0
1
1
1
2
1
3
1
4
1 Fan
2
Large spring washer
3
Small spring washer
4 W
asher
(black)
5 Retaining
ring
6 Bearing
7 Carrier
housing
8 Spacer
9 Bearing
10 W
ave-spring
washer
11 Retaining
ring
12
W
asher (Brass color)
13 Drive
gear
14 Lock-nut
DBW 20
1
0
58
60
