weinor BiRec MVLED User Manual

BiConnect BiRec MVLED/MLED
Version 4
2020-07-08
Assembly and installation instructions/ Instructions de montage et d’installation
Item number/
We reserve the right to make technical changes/ Sous reserve de modifications techniques
Numéro d’article
116692-0000
Page 13/28
8 Technical data
Power supply
230 V
Frequency
50 HZ
Maximum power input of motor
250 W
Certified for Becker R30/17C PS(+), R40/17C PS(+),
50/11C PS(+)
Maximum power input of light
32 W;
at least. 1 – max. 11 LEDs, weinor system; max. 680 mA
IP code
IP 54
Permissible ambient temperature
20 to +80°C
Radio frequency
868.3 MHz
Radio protocol
BiConnect/ Elero/ Griesser
Supply line
AMP male connector, 2-pole with earthing cable and ring-
type terminal for 6 m cable with safety plug
Awning motor input
AMP female connector, 4-pole
Blue – black – brown – green/yellow
Motor input for Valance Plus
(BiRec MVLED only)
AMP female connector, 4-pole
Blue – black – brown – green/yellow
Light connection
Female push-on connector, 2.8 mm (red/black)
Awning switching method
Awning runs on self-sustaining power until end position is
recognised;
coordinated operating mode with retraction protection
(BiRec MVL only)
Light switching mode
Light on/off
Dimming of light
Compatibility
• BiEasy hand transmitter (bidirectional only)
• Remoto hand transmitter (unidirectional only)
• BiEasy wall transmitter 1MW-3V
• BiSens Agido-3V product protection sensor
• BiSens SWR 230 V sun/ wind/ rain sensor
• BiSens SW 230 V sun/ wind sensor
• BiSens SW Solar sun/ wind sensor
• BiSens Sun Solar sun sensor
9
Disposal
Do not dispose of used or defective electrical or electronic devices in household waste. They must
be returned to the manufacturer or taken to a local collection point.
