Winterhalter PT-M User Manual

Operation | 6 | English
Operating instructions PT Series | 89014547; 2021-03 | 39
6.3 Opening/closing the hood (automatic hood optional)
There are two options for opening / closing the hood without having to start a programme (e.g. during idle periods):
Open / close the hood using the start button
Ø Press the start button (1) on the front cover for 2 seconds.
1
Open the hood via the display
The position of the hood is indicated by the arrows on the pictogram.
Ø Press the “Open the hood” button.
Close the hood via the display
The position of the hood is indicated by the arrows on the pictogram.
Ø Press the “Close the hood” button.

Winterhalter PT-M Specifications

General

Rack size	500 x 500 mm
Water consumption per cycle	2.4 liters
Total connected load	9.5 kW
Protection class	IPX5
Power supply	400 V / 50 Hz / 3~
