FAULT FINDING AND DIAGNOSIS
Greenstar i System Compact - 6 720 807 726 (2013/05)62
7.4.7 USING THE TEST MENU
This menu enables the testing of the functionality of components in an
ON/OFF mode.The duration of each test is limited to 30 seconds.
1.Select menu TEST via the and scroll buttons.
2.Press the button for one second to enter TEST.
Fig. 125 Selecting test menu
SELECTING A TEST COMPONENT
Refer to table 19 and use the and arrow buttons to scroll
through the various test options.
Fig. 126 Scroll through test options
TESTING THE COMPONENT
▶ Select a component to test.
▶ Press the button, the value 0 will flash.
▶ Use the arrow button to change the value to a flashing 1.
▶ Press to confirm the change, the value 1 will stop flashing and a
will displayed for 3 seconds.
The test will run for 30 seconds or until the value is changed back to 0.
Fig. 127 Testing component
