6 Freedom SW 3000 Installation Guide
Planning the Installation
This section provides information to help you plan for a basic installation of
the Freedom SW 3000.
As your system configuration is determined, record the details in
Information About Your System of the Freedom SW 3000 Sine Wave
Inverter/Charger Owner’s Guide.
Two Key Performance Factors
Two key factors in particular will have a major impact on system
performance.
Size and Length of DC Cables
To select the appropriate size and length of DC cables, see “DC Cabling” on
page 13.
The DC cables should be as short as possible and large enough to handle the
required current, in accordance with the electrical codes or regulations
applicable to your installation. If there are long battery cables which are in
excess of 10 feet each and not of sufficient size, the voltage drop across the
cables will have a negative impact on overall system performance.
Mounting Location of the Freedom SW 3000
To choose an appropriate location for mounting the inverter/charger, see
“Step 1: Choosing a Location for the Inverter/Charger” on page 18.
