14 Freedom SW 3000 Installation Guide
Planning
DC Grounding
The inverter/charger DC (chassis) ground terminal needs to be connected to
the vehicle chassis by a minimum No. 8 AWG copper conductor that is
either insulated (green) wire rated 90 °C or bare copper.
