975-0546-01-01 17
This guide for use by qualified installers only.
Installing the Inverter/Charger
Overview
This section provides detailed information on installing the Freedom SW
3000. The overall procedure is divided into eight steps:
Step 1: Choosing a Location for the Inverter/Charger
Step 2: Mounting the Inverter/Charger
Step 3: Connecting the AC Input and AC Output Wires
Step 4: Connecting the DC Cables
Step 5: Connecting the Battery Temperature Sensor (BTS)
Step 6: Connecting to the Network
Step 7: Performing Checks Prior to Initial Start-Up
Step 8: Testing Your Installation
