975-0546-01-01 23
Installing the Inverter/Charger
This guide for use by qualified installers only.
Step 3: Connecting the AC Input and AC Output Wires
General AC Wiring Considerations
AC and DC Wiring Separation Do not mix AC and DC wiring in the
same conduit or panel. Consult the applicable installation code for details
about DC wiring and AC wiring in vicinity to each other.
AC Input and Output Isolation The AC input and output circuits of this
inverter/charger are isolated from each other when in invert mode to ensure
safe operation. This isolation must be maintained in the installation, by
being sure not to connect AC input and output wiring to a common point.
For example, do not route the AC input and output neutrals to a common
neutral bus.
AC Wiring Compartment For your reference, the AC wiring
compartment is shown in Figure 4 on page 24.
AC Knockouts There are two dual 1.0"/ 3/4" trade-size knockouts on the
side panel for AC wiring. Use the same trade size of strain relief as the trade
size of the knockout(s) you are using.
AC Wiring Terminals The AC wiring terminals accept cables of a
specific size. See “AC Wiring” on page 11 for required sizes.
FIRE, ELECTRICAL SHOCK, AND ENERGY HAZARDS
Make sure wiring being connected to the inverter/charger is disconnected
(physically or by opening the breaker) from all electrical sources before
handling. All wiring must be done in accordance with local and national
electrical wiring codes.
Failure to follow these instructions will result in death or serious
injury.
