975-0546-01-01 37
Installing the Inverter/Charger
This guide for use by qualified installers only.
Step 7: Performing Checks Prior to Initial Start-Up
Before testing your installation, ensure these conditions are met:
❐ Chassis and AC grounds are properly installed.
❐ AC input connections and AC output connections are wired correctly
on the terminal block and not reversed.
❐ Positive (+) battery cable is connected to the positive (+) battery
terminal through the DC fuse and disconnect switch or DC circuit
breaker.
❐ Negative (–) battery cable is connected to the negative (–) battery
terminal.
❐ Battery voltage is within the proper range for this unit
(10–16 volts DC).
❐ DC disconnect switch or breaker is turned off.
❐ AC input and output breakers are turned off.
❐ All connections are tight.
