XEROX WIDE FORMAT COPY SYSTEM Appendices • 151
Appendix 5
File formats supported by the Controller with Firmware 10.0 are shown in the list
below.
• CalComp 906/907/PCI
• HP-GL (HP7585/6)
• HP-GL/2
• TIFF 6.0
• CGM
• VCGL
• VDS (VRF, Block Raster, Compressed Raster, VOF)
• Versatec Raster/Green Sheet
• Post Script
Appendix 6
The HFT and the KLF Controller (X2 TECH) have four LED status indicators as
shown in Table 12 below.
Table 12. UP8 Controller LED status indicators
LED Number Color Indicated Condition
LED 1 Green "Ready." Indicates that the Controller is
powered up and ready to process
incoming jobs.
LED 2 Green "Busy." Indicates that the Controller is
busy processing a job.
LED 3 Yellow "Mismatch." Indicates that a media
mismatch, which may be blocking the
print queue, has occurred. Also
displayed when the Controller's
Accounting disk is full, or when the
Controller has reached its Accounting
record limit. Check the Web PMT's Main
Page to determine the problem.
LED 4 Red "Attention." Indicates that a Printer or
Finisher fault has occurred. May indicate
a paper jam, out of toner condition, out of
media condition, or a communications
problem with one of the devices.
During power-on self test (POST), the firmware will light LEDs 2, 3, and 4. After
POST has successfully completed, LEDs 2, 3, and 4 will be switched OFF, and
LED 1 will be switched ON. If POST did not successfully complete, all 4 LEDs
will be switched OFF (i.e., they will be unlit).
