• If you remove the Wi-Fi network connection module, the primary network connection is set to Ethernet.
The following features are available only over the primary network connection:
• IPsec
• SMTP
• SNTP
• WSD scan
• Scan to SFTP, Scan to SMB, Scan to Email
• LDAP
• UPnP discovery
• ThinPrint
• EIP Web Service
To configure the primary network at the control panel:
1. At the printer control panel, press the HHoommee button.
2. Log in as administrator. For details, refer to the System Administrator Guide at www.xerox.com/office/
VLC71XXdocs.
3. Touch DDeevviiccee >> CCoonnnneeccttiivviittyy >> PPrriimmaarryy NNeettwwoorrkk.
4. Select the appropriate network connection type for the device.
5. To apply the changes and restart the device, at the prompt, touch RReessttaarrtt NNooww.
Connecting to Wi-Fi Direct
You can connect to your printer from a Wi-Fi mobile device, such as a tablet, computer, or smartphone, using Wi-Fi
Direct. Wi-Fi Direct is disabled by default.
Note: Wireless networking is available only on printers with the optional Wireless Network Adapter installed.
To connect with Wi-Fi Direct, follow the directions provided with your mobile device.
CONNECTING TO A TELEPHONE LINE
WWaarrnniinngg:: To reduce the risk of fire, use only No. 26 American Wire Gauge (AWG) or larger
telecommunication line cord.
1. Ensure that the printer is powered off.
2. Connect a standard RJ11 cable, No. 26 American Wire Gauge (AWG) or larger, to the Line port on the back of
the printer.
3. Connect the other end of the RJ11 cable to an operating telephone line.
4. Power on the printer.
5. Enable and configure the Fax functions.
Xerox
®
VersaLink
®
C71XX Series Color Multifunction Printer User Guide 49
Getting Started

Xerox VersaLink C7120 Specifications

General

Color	Yes
N-up printing	2, 4, 6, 8, 9, 16
Duplex printing	-
Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Time to first page (black, normal)	6.9 s
Time to first page (color, normal)	8.8 s
Print speed (black, normal quality, A3)	11 ppm
Print margins (top, bottom, right, left)	4 mm
Print speed (black, normal quality, A4/US Letter)	20 ppm
PCL fonts	83
Printer fonts	PCL, PostScript
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Copy, Print, Scan
Maximum duty cycle	87000 pages per month
Recommended duty cycle	0 - 5500 pages per month
Number of PostScript fonts	136
Number of print cartridges	4
Page description languages	HP-GL, JPEG, PCL 5e, PCL 6, PDF, PostScript 3, TIFF
Display	LCD
Control type	Touch
Product color	Blue, White
Display diagonal	7 \
Market positioning	Business
Internal memory	4096 MB
Processor cores	2
Processor frequency	1050 MHz
Sound power level (standby)	4.1 dB
Sound power level (printing)	6.9 dB
HDD capacity	320 GB
Browser supported	Microsoft Internet Explorer, Microsoft Edge, Mozilla Firefox, Apple Safari, Google Chrome
Languages support	Multi
Faxing	No
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, SNMPv3, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Mopria Print Service
Supported network protocols (IPv4)	TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD LDAP Bonjour /AirPrint
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (sleep)	0.4 W
Power consumption (standby)	94 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 85 %
Optional connectivity	Wireless LAN
Scan to	E-mail, Network folder, SMB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Maximum scan area	297 x 431.8 mm
Output color depth	24 bit
Output grayscale depth	8 bit
Image formats supported	JPEG, TIFF
Document formats supported	PDF
Optical scanning resolution	600 x 600 DPI
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Other operating systems supported	HP-UX 11, HP-UX 11.11, HP-UX 11.23, HP-UX 11.31, IBM AIX 5.3, IBM AIX 6.1, IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 10 SPARC, Solaris 11, Solaris 11 SPARC, Solaris 8, Solaris 9, Solaris 9 SPARC
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Time to first copy (black, normal)	5.7 s
Time to first copy (color, normal)	8.1 s
Copy speed (black, normal quality, A4)	20 cpm
Custom media width	88.9 - 297 mm
Custom media length	98.4 - 431.8 mm
Paper tray media types	Bond paper, Card stock, Heavy printing media, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 256 g/m²
ISO A-series sizes (A0...A9)	A3, A4
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Total input capacity	620 sheets
Total output capacity	250 sheets
Paper tray 1 input capacity	520 sheets
Multi-Purpose tray input capacity	100 sheets
Included cartridge capacity (CMY)	9800 pages
Included cartridge capacity (black)	16100 pages

Weight and Dimensions

Depth	670.8 mm
Width	590 mm
Height	766.5 mm
Weight	62500 g
