W130 / W110 Scanner Scanner Options, Maintenance and Troubleshooting
6-12 User Guide
Replacing the Double feed Roller
1. Flip open the double feed prevention roller cover.
2. Lift the roller up and out of the scanner.
3. Discard the roller, it cannot be repaired or reused.
4. Take the new roller out of its packaging.
5. Align the roller bar with the brackets in the roller compartment. Make sure the groove on the
right side of the roller bar is aligned so that it slides in place into the U shape of the bracket.
6. The roller is properly in place when you cannot rotate the metal bar of the roller.
7. Close the double feed prevention roller cover when you are finished.
Scanner Status Message Table
The LCD displays an error image or code. The following table lists the images, possible causes and
common resolutions.
