Xilinx Alveo U200 User Manual

xilinx_u250_gen3x16_xdma_shell_3_1
logic-uuid:
bd5fb8abab266c3265918257b5048e88
interface-uuid:
f2f6c5e1273e78948f2c4806221462f2
Under Partitions running on FPGA both the base
xilinx_u250_gen3x16_base_3 and the shell
xilinx_u250_gen3x16_xdma_shell_3_1 parons will be displayed.
Aer the shell paron is programmed, it is not necessary to reprogram it unless the system
is rebooted.
xbutil validate
The xbutil validate command validates the correct installaon by performing the following
set of tests:
1. Validates the device found.
2. Checks PCIe link status.
3. Runs a verify kernel on the card.
4. Performs the following data transfer tests:
a. DMA test - Data transfer between host and card memory through PCIe.
b. Memory test - Data transfer between kernels and card memory.
Prior to running an applicaon, including the validaon applicaon, it is necessary to rst
program the shell paron to the card using the following command. See "Obtaining xbmgmt
command opons" to obtain the card_bdf and shell_name opons. Aer the shell paron
is programmed, it is not necessary to reprogram it unless the system is warm or cold rebooted.
$ sudo /opt/xilinx/xrt/bin/xbmgmt partition --program --name <shell_name> --
card <card_bdf>
With the shell programmed, run the validate command as follows:
$ /opt/xilinx/xrt/bin/xbutil validate -d <card_bdf>
where card_bdf is the BDF of the card to be validated. If -d is not specied, the command will
validate all cards in the system.
Chapter 5: Card Bring-Up and Validation
UG1301 (v1.8) February 5, 2021 www.xilinx.com
Getting Started with Alveo Accelerator Cards 33
Send Feedback
