59
Taking pictures
1. Connect the camera-equipped speaker microphone (MH-85A11U) to the DATA termi-
nal of the FT5DR/DE.
• When connecting or disconnecting the MH-85A11U, turn off the FT5DR/DE.
• When receiving an AM radio broadcast signal with the camera microphone connected,
noise may occur, but this is not a malfunction.
2. Point the camera lens at the object to be photographed and press the shutter button
[
]on the microphone.
•
The captured image appears on the LCD.
•
Touch the image, to temporarily turn OFF the display of buttons and view the en-
tire photo. Touch the image again to display the buttons.
3. To save the image onto the microSD memory card, touch [SAVE].
Press the [BACK] key or touch [DEL] to return the display to the previous operating
screen without saving the image.
4. To transmit the saved image to other transceivers, press the [D-TX] key on the MH-
85A11U or touch [SEND].
5. Press the [BACK] key or touch [OK] to return to the normal operation.
Viewing the Saved Image
1. Press the [F ] key, and then touch [LOG].
If [LOG] is not displayed, touch [BACK
] to display [LOG] and then touch it.
2. Touch [PICT].
Displays the saved image data list.
3. Touch the image to be displayed.
•
Displays the selected image.
•
To transmit the image to other transceivers, touch [SEND] or [FWD]. When the
transfer is complete, the screen in step 3 will return.
4. Press the [BACK] key several times to return to the previous operating screen.
GPS Function
FT5DR/DE is equipped with GPS (Global Positioning System) reception function.
When receiving signals from GPS satellites, the current position (latitude, longitude, alti-
tude) can be calculated and displayed within the tolerance of several meters. In addition,
GPS can receive the exact time from a satellite-mounted atomic clock.
• When the GPS function is active, the power consumption increases by about 15 mA.
• To turn the GPS function ON/OFF:
Press and hold the [F ] key
[APRS]
[20 GPS POWER]
