20
Operation
Turning the Transceiver ON
Press and hold the Power (Lock) switch to turn the trans-
ceiver ON.
●
Turning the transceiver OFF
Press and hold the Power (Lock) switch again to turn
the transceiver OFF.
●
Inputting the call sign
The first time the transceiver is turned ON after it is
purchased; input your own call sign.
1. Press the [F ] key to proceed to the call sign in-
put screen.
•
When the transceiver is turned ON the second time,
and subsequently, the opening screen appears
followed by the frequency screen.
•
Input call sign may be changed from Setup Menu
[CALLSIGN] (page 68).
2. Input the call sign (toggle the alphabet input screen,
and the number input screen when necessary).
3. Save the entered call sign:
4. Press the PTT switch or press and hold the [F ]
key.
• Up to 10 characters (letters, numbers, and symbols)
can be entered.
• Characters that may be inputted for the call sign are
the numbers 0-9, letters A-Z (upper case), the hyphen
and the slash.
Please enter your
Callsign.
(Max 10 letters)
Adjusting the Volume Level
1. Rotate the VOL knob to adjust the volume to a com-
fortable level.
•
The transceiver volume levels for the A-band and
B-band are adjusted separately.
•
The transceiver volume levels for the AM broad-
cast band and the FM broadcast band are adjusted
separately.
The fidelity (audio pitch) of the received audio in C4FM digital mode can be
emphasized in the high range or the low range. Use Set Mode [TX/RX]
[DIGITAL]
[5 AUDIO PITCH] (see page 63)
