RF-9

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG YAESU P/N VERS.

LOT

SIDE

LAY ADR

RF Unit

Parts List

FT2DR/DE Technical Supplement

PCB with Components CS2353702 USA: A2U

CS2353703 EXP: B3

CS2353704 EU: B2

CS2353705 EU: C2

CS2353706 AUS: H2

C 1001 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BA01D K22178288 1- B b1

C 1002 CHIP CAP. 12pF 50V CH GRM1552C1H120JA01D K22178214 1- A A1

C 1003 CHIP CAP. 47pF 50V CH GRM1552C1H470JA01D K22178228 1- A A1

C 1004 CHIP CAP. 12pF 50V CH GRM1552C1H120JA01D K22178214 1- A A1

C 1005 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 1- A A1

C 1006 CHIP CAP. 82pF 50V CH GRM1552C1H820JA01D K22178234 1- B b1

C 1007 CHIP CAP. 82pF 50V CH GRM1552C1H820JA01D K22178234 1- B b1

C 1008 CHIP CAP. 56pF 50V CH GRM1552C1H560JA01D K22178230 1- B b1

C 1009 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B b1

C 1014 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A B2

C 1015 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 1- B b1

C 1016 CHIP CAP. 5pF 50V CH GRM1552C1H5R0CA01D K22178207 1- B b1

C 1017 CHIP CAP. 3pF 50V CJ GRM1553C1H3R0BA01D K22178290 1- B b1

C 1018 CHIP CAP. 7pF 50V CH GRM1552C1H7R0DA01D K22178209 1- B b1

C 1019 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 1- B b1

C 1021 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 1- A A1

C 1022 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A B1

C 1023 CHIP CAP. 39pF 50V CH GRM1552C1H390JA01D K22178226 1- B b1

C 1024 CHIP CAP. 33pF 50V CH GRM1552C1H330JA01D K22178224 1- B b1

C 1025 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A A2

C 1026 CHIP CAP. 15pF 50V CH GRM1552C1H150JA01D K22178216 1- A A1

C 1027 CHIP CAP. 15pF 50V CH GRM1552C1H150JA01D K22178216 1- B b1

C 1028 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 1- A A1

C 1029 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B b2

C 1030 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A A1

C 1031 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B b1

C 1033 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B b1

C 1035 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B b1

C 1036 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B b1

C 1037 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B b1

C 1038 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B b1

C 1039 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B b1

C 1041 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B b1

C 1042 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A B2

C 1043 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A B2

C 1044 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 1- B a4

C 1045 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A A2

C 1046 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a4

C 1048 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b1

C 1049 CHIP CAP. 3pF 50V CJ GRM1553C1H3R0BA01D K22178290 1- B b1

C 1050 CHIP CAP. 8pF 50V CH GRM1552C1H8R0DA01D K22178210 1- B b1

C 1051 CHIP CAP. 11pF 50V CH GRM1552C1H110GA01D K22179731 1- B b1

C 1052 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b1

C 1053 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BA01D K22178291 1- B b1

C 1054 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b1

C 1055 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b1

C 1056 CHIP CAP. 39pF 50V CH GRM1552C1H390JA01D K22178226 1- B b1

C 1057 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BA01D K22178287 1- B b1

C 1059 CHIP CAP. 11pF 50V CH GRM1552C1H110GA01D K22179731 1- A B1

C 1060 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A B1

C 1061 CHIP CAP. 4pF 50V CH GRM1552C1H4R0BA01D K22178291 1- A B1

C 1062 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A B1

C 1063 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A B1

C 1064 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 1- A B1

C 1065 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BA01D K22178287 1- A B1

C 1067 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A B2

C 1068 CHIP CAP. 22pF 50V CH GRM1552C1H220GA01D K22179707 1- A B1

C 1069 CHIP CAP. 22pF 50V CH GRM1552C1H220GA01D K22179707 1- B b2

C 1070 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A B1

C 1071 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b2

C 1072 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A B1

C 1073 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b2

C 1074 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A B1

C 1075 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A B1

C 1076 CHIP CAP. 4.7uF 4V BJ AMK105BJ475MV-F K22068801 1- A A1

C 1077 CHIP CAP. 47pF 50V CH GRM1552C1H470JA01D K22178228 1- A B1

C 1078 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A B1

C 1079 CHIP CAP. 22pF 50V CH GRM1552C1H220JA01D K22178220 1- A C1
