RF-20
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG YAESU P/N VERS. LOT SIDE LAY ADR
RF Unit
Parts List
FT2DR/DE Technical Supplement
Q 1024 TRANSISTOR 2SC5646A(TAPE) G3356468 1- B b1
Q 1025 TRANSISTOR 2SC5646A(TAPE) G3356468 1- A B1
Q 1026 IC MB15A01PFV1-G-BND-EFE1 G1092545 1- A B4
Q 1027 TRANSISTOR DTC143ZM G3070400 1- B b4
Q 1028 TRANSISTOR DTC143ZM G3070400 1- B a3
Q 1029 TRANSISTOR 2SC5488A-TL G3354888A 1- B b1
Q 1030 TRANSISTOR 2SC5646A(TAPE) G3356468 1- B a1
Q 1031 TRANSISTOR 2SC5646A(TAPE) G3356468 1- A B1
Q 1032 TRANSISTOR 2SC5646A(TAPE) G3356468 1- A B2
Q 1033 TRANSISTOR 2SC5646A(TAPE) G3356468 1- B a2
Q 1034 TRANSISTOR 2SC5646A(TAPE) G3356468 1- A B1
Q 1035 IC NJU7007F3-TE1 G1093617 1- A B2
Q 1036 TRANSISTOR 2SC5488A-TL G3354888A 1- B a3
Q 1037 TRANSISTOR MT4S300T G3070482 1- B a3
Q 1038 IC NJU7007F3-TE1 G1093617 1- A B2
Q 1039 TRANSISTOR 2SC5374-TL G3353748 1- B a2
Q 1040 TRANSISTOR 2SC5374-TL G3353748 1- B a3
Q 1041 TRANSISTOR MT4S300T G3070482 1- B a3
Q 1042 TRANSISTOR 2SC5226A-5-TL-E G3070417 1- B c3
Q 1043 TRANSISTOR 2SC4915-O(TE85L.F) G3349158O 1- A A4
Q 1044 TRANSISTOR DTC144EM T2L G3070309 1- A C3
Q 1045 IC R2A20178NP G1094776 1- A C3
Q 1046 TRANSISTOR DTC144EM T2L G3070309 1- A C2
Q 1047 TRANSISTOR DTC144EM T2L G3070309 1- A C2
Q 1049 IC LM2904PWR G1094010 1- B c3
Q 1050 TRANSISTOR DTA114TE TL G3070264 1- A A3
Q 1051 TRANSISTOR EMD2 T2R G3070312 1- A A3
Q 1052 TRANSISTOR 2SC4915-O(TE85L.F) G3349158O 1- A A4
Q 1053 TRANSISTOR 2SC4915-O(TE85L.F) G3349158O 1- B a2
Q 1054 TRANSISTOR 2SC4915-O(TE85L.F) G3349158O 1- A C2
Q 1055 FET 2SK3475(T2LVX.F) G3070318 1- B c2
Q 1056 TRANSISTOR DTC144EM T2L G3070309 1- A A3
Q 1057 IC MB15A01PFV1-G-BND-EFE1 G1092545 1- A A3
Q 1058 TRANSISTOR 2SC4915-O(TE85L.F) G3349158O 1- A A3
Q 1059 FET 2SK3541 T2L G3835417 1- B c4
Q 1060 FET 2SK3541 T2L G3835417 1- A B5
Q 1062 FET 2SK3541 T2L G3835417 1- A A3
Q 1063 IC NJM2552V-TE1 G1094382 1- A A4
Q 1064 IC NJM2552V-TE1 G1094382 1- A B4
Q 1066 TRANSISTOR 2SC5658 T2L Q/R G3356588 1- A A4
Q 1067 FET SSM3J16FS(TE85L.F) G3070429 1- A B4
Q 1068 TRANSISTOR 2SC5658 T2L Q/R G3356588 1- A B4
Q 1069 FET SSM3J16FS(TE85L.F) G3070429 1- A B4
Q 1070 FET RFM07U7X G3070496 1- A A2
Q 1071 TRANSISTOR DTC143ZM G3070400 1- B c3
Q 1072 TRANSISTOR DTC143ZM G3070400 1- B c4
Q 1073 TRANSISTOR DTC143ZM G3070400 1- B b4
Q 1074 FET SSM3J16FS(TE85L.F) G3070429 1 A B3
Q 1074 FET 2SJ364-P(TX) G3703648P 2- A B3
Q 1074 FET 2SJ145-T111-1D G3701458 7- A B3
Q 1075 FET SSM3J16FS(TE85L.F) G3070429 1- A B3
Q 1076 IC TS3A24159DGSRG4 G1094892 1- A B4
Q 1077 TRANSISTOR 2SC5488A-TL G3354888A 1- B b3
Q 1078 TRANSISTOR 2SC5488A-TL G3354888A 1- B b3
Q 1079 TRANSISTOR MT4S300T G3070482 1- B b3
Q 1080 TRANSISTOR MT4S300T G3070482 1- B b3
Q 1081 FET RTM002P02(TAPE) G3070347 1- A B2
Q 1082 TRANSISTOR 2SC5374-TL G3353748 1- B b3
Q 1083 FET RTM002P02(TAPE) G3070347 1- A B3
Q 1084 TRANSISTOR 2SC5658 T2L Q/R G3356588 1- A B2
Q 1085 FET RTM002P02(TAPE) G3070347 1- A B3
Q 1086 TRANSISTOR DTC144EM T2L G3070309 1- A B2
Q 1087 TRANSISTOR EMB3 T2R G3070303 1- A B2
Q 1088 TRANSISTOR EMB3 T2R G3070303 1- A B3
Q 1089 TRANSISTOR 2SC5658 T2L Q/R G3356588 1- B a3
Q 1090 TRANSISTOR 2SC5658 T2L Q/R G3356588 1- A B3
Q 1091 IC XC6371A650DR G1094584 1- B b5
Q 1092 FET RSE002P03TL G3070472 1- A A5
Q 1093 FET 2SK3541 T2L G3835417 1- A B5
Q 1094 TRANSISTOR DTC144EM T2L G3070309 1- A A2
Q 1095 TRANSISTOR 2SC5374-TL G3353748 1- B b3
Q 1096 FET RTM002P02(TAPE) G3070347 1- A B3
Q 1097 TRANSISTOR EMB3 T2R G3070303 1- A B3
