RF-22
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG YAESU P/N VERS. LOT SIDE LAY ADR
RF Unit
Parts List
FT2DR/DE Technical Supplement
R 1052 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B1
R 1053 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- A B1
R 1054 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 1- A A1
R 1055 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B1
R 1056 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- A C1
R 1057 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- A C1
R 1058 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- A C1
R 1059 CHIP RES. 3.9k 1/16W 5% RMC1/16S 392JTH J24189032 1- A C2
R 1060 CHIP RES. 3.9k 1/16W 5% RMC1/16S 392JTH J24189032 1- A C2
R 1061 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- A B3
R 1062 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 1- A B4
R 1063 CHIP RES. 1.8k 1/16W 5% RMC1/16S 182JTH J24189028 1- A B4
R 1064 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 1- A B4
R 1065 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A B4
R 1066 CHIP RES. 1.2k 1/16W 5% RMC1/16S 122JTH J24189026 1- A B4
R 1067 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A4
R 1068 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B b1
R 1069 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b1
R 1070 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b1
R 1071 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b1
R 1072 CHIP RES. 56k 1/16W 5% RMC1/16S 563JTH J24189046 1- B b1
R 1073 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B b1
R 1074 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B1
R 1075 CHIP RES. 56k 1/16W 5% RMC1/16S 563JTH J24189046 1- A B1
R 1076 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A B1
R 1077 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B1
R 1078 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B2
R 1079 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B1
R 1080 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 1081 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 1082 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A B1
R 1083 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 1084 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B1
R 1085 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B1
R 1086 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A B1
R 1087 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B4
R 1088 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B4
R 1089 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B4
R 1090 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- A B4
R 1091 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 1- A B4
R 1092 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b1
R 1093 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- B b1
R 1094 CHIP RES. 560 1/16W 5% RMC1/16S 561JTH J24189022 1- B b1
R 1095 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a1
R 1096 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a1
R 1097 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1 B a1
R 1097 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 W/ CE LABEL 2- B a1
R 1097 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 W/O CE LABEL 2- B a1
R 1098 CHIP RES. 68 1/16W 5% RMC1/16S 680JTH J24189011 1- B a1
R 1099 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B1
R 1100 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B1
R 1101 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B1
R 1102 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A B1
R 1103 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A B2
R 1104 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1 A B2
R 1104 CHIP RES. 33 1/16W 5% RMC1/16S 330JTH J24189007 W/ CE LABEL 2- A B2
R 1104 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 W/O CE LABEL 2- A B2
R 1105 CHIP RES. 56k 1/16W 5% RMC1/16S 563JTH J24189046 1- B a2
R 1106 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A B2
R 1107 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b2
R 1108 CHIP RES. 150 1/16W 5% RMC1/16S 151JTH J24189015 1 B a2
R 1108 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 W/ CE LABEL 2- B a2
R 1108 CHIP RES. 150 1/16W 5% RMC1/16S 151JTH J24189015 W/O CE LABEL 2- B a2
R 1109 CHIP RES. 270k 1/16W 5% RMC1/16S 274JTH J24189054 1- A B1
R 1110 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- B a2
R 1111 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A B1
R 1112 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- A B1
R 1113 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- A B1
R 1114 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A B2
R 1115 CHIP RES. 2.2M 1/16W 5% RMC1/16S 225JTH J24189065 1- A B2
R 1116 CHIP RES. 2.2M 1/16W 5% RMC1/16S 225JTH J24189065 1- A B2
R 1117 CHIP RES. 390k 1/16W 0.5% MCR01MZPD3903 J24189331 1- A B2
R 1118 CHIP RES. 680k 1/16W 5% RMC1/16S 684JTH J24189059 1- A B3
