CNTL-11
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG YAESU P/N VERS. LOT SIDE LAY ADR
CNTL Unit
Parts List
FT2DR/DE Technical Supplement
R 2018 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B c4
R 2021 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c4
R 2023 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B c2
R 2029 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B c2
R 2033 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c4
R 2036 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B b4
R 2037 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a2
R 2038 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b1
R 2039 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B c4
R 2040 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B b4
R 2041 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- B a2
R 2048 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c4
R 2049 CHIP RES. 82k 1/16W 0.5% MCR01MZPD8202 J24189385 1- B c2
R 2050 CHIP RES. 150k 1/16W 0.5% MCR01MZPD1503 J24189328 1 B c2
R 2050 CHIP RES. 100k 1/16W 0.5% MCR01MZPD1003 J24189386 2- B c2
R 2051 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B c2
R 2052 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b4
R 2053 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B b4
R 2054 CHIP RES. 6.8 1/16W 5% RMC1/16S 6R8JTH J24189068 1- B a2
R 2055 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c4
R 2056 CHIP RES. 22 1/16W 0.5% RR0510R-220-D J24189079 1- B a2
R 2057 CHIP RES. 6.8 1/16W 5% RMC1/16S 6R8JTH J24189068 1- B a2
R 2061 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B b4
R 2062 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B b4
R 2063 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c4
R 2064 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c4
R 2065 CHIP RES. 22 1/16W 0.5% RR0510R-220-D J24189079 1- B a2
R 2066 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c4
R 2067 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c4
R 2074 CHIP RES. 330k 1/16W 0.5% MCR01MZPD3303 J24189330 1- B b2
R 2075 CHIP RES. 68k 1/16W 0.5% MCR01MZPD6802 J24189384 1- B b2
R 2076 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c4
R 2077 CHIP RES. 1.8k 1/16W 5% RMC1/16S 182JTH J24189028 1- A A1
R 2078 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c4
R 2082 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a2
R 2083 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B a2
R 2086 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A A1
R 2087 CHIP RES. 1.5k 1/16W 0.5% RR0510P-152-D J24189123 1- B a2
R 2088 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c4
R 2091 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- A A1
R 2092 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- A A1
R 2093 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A A1
R 2094 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B a2
R 2095 CHIP RES. 3.9k 1/16W 5% RMC1/16S 392JTH J24189032 1- A A1
R 2096 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a3
R 2097 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B a3
R 2098 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1 B b2
R 2098 CHIP RES. 270k 1/16W 5% RMC1/16S 274JTH J24189054 2- B b2
R 2099 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a2
R 2100 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a2
R 2101 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a2
R 2102 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B c4
R 2103 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B a2
R 2108 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A A4
R 2111 CHIP RES. 39 1/16W 5% RMC1/16S 390JTH J24189008 1- A C2
R 2112 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- A A4
R 2119 CHIP RES. 39 1/16W 5% RMC1/16S 390JTH J24189008 1- A C2
R 2120 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A C2
R 2121 CHIP RES. 27k 1/16W 0.5% RR0510R-273-D J24189153 1- B c2
R 2122 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C2
R 2123 CHIP RES. 5.6 1/16W 5% RMC1/16S 5R6JTH J24189067 1- A C1
R 2124 CHIP RES. 5.6 1/16W 5% RMC1/16S 5R6JTH J24189067 1- A C1
R 2125 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c2
R 2126 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A C2
R 2127 CHIP RES. 1.8k 1/16W 5% RMC1/16S 182JTH J24189028 1- A C2
R 2128 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b2
R 2129 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C1
R 2130 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B c1
R 2131 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- B c2
R 2133 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b1
R 2134 CHIP RES. 390k 1/16W 5% RMC1/16S 394JTH J24189056 1- B c2
R 2135 CHIP RES. 1k 1/16W 0.5% RR0510P-102-D J24189119 1- A A1
R 2136 CHIP RES. 1k 1/16W 0.5% RR0510P-102-D J24189119 1- A A1
