10
Mounting the Rotator and Antenna
Installation of Rotator and Antenna on Tower
The procedure for installing the rotator depends on the type of tower used. The following in-
structions are generally applicable to most guyed, crank-up, or roof towers.
1. Attach the rotator to the tower’s rotator mounting plate, using the supplied M8 x 16 bolts
and spring washers. It is recommended that the tips of the bolts be lightly dipped in lubri-
cating grease, to ease disassembly in the future.
2. If a thrust bearing (such as the optional Yaesu model GS-065) is to be utilized, mount it on
the top of the tower (see Figure 4) using the supplied hardware.
3. Using a “gin pole” or other raising xture, insert the antenna mast through the bearing from
above, and set the mast in the rotator’s mast clamps. Do not tighten the mast clamps at
this time;just secure the U-bolts to the point where the mast is held in place, but is allowed
to rotate freely.
4. Partly tighten the thrust bearing’s mast bolts, so as to center the mast in the thrust bear-
ing. When you are satised that the mast is centered, back off slightly on each of the thrust
bearing’s mast bolts, and (if possible) lift the mast by a very small amount (approximately 5
mm or 3/16”), just enough to lift the bottom of the mast slightly off the top of the rotator. Now
re-tighten the thrust bearing’s mast bolts to secure the mast in place. This procedure takes
all the weight of the mast and antennas off of the rotator; all weight is being carried by the
thrust bearing. If no thrust bearing is used, the mast should be allowed to rest on the top of
the rotator.
5. Verify that the mast rotates freely in the mast clamps, and that the mast is properly centered
in the clamps. Now tighten the nuts on the U-bolts of the mast clamp.
Caution: Do not over-tighten the nuts on the mast clamps. They should be tightened until
the spring washer becomes at, then tightened further by 1/2 to one turn maxi-
mum.
6. Install the rotator control cable’s round plug into the jack on the side of the rotator’s base,
and tighten the connector ring to secure the connector. Slide the rubber boot over the con-
nector; while putting a slight amount of inward pressure on the rubber boot, use electrical
tape to secure the back end of the rubber boot to the cable. This slight inward pressure on
the rubber boot will enhance the weatherproong of the installation. Secure the control ca-
ble to the tower in several places, using electrical tape and/or UV-resistant cable ties.
7. Install the antenna(s) on the mast. Use a compass to align the forward end of the beam
toward North (0º) or whichever direction to which you set the “Left Stop” in Step 12 of
the previous section.
8. Provide sufcient slack in the coaxial cable such that the antenna can rotate over its full
450º range without putting any tension on the coax (see Figure 8). Secure the coax to the
tower, using electrical tape and/or UV-resistant cable ties.
9. Installation is now complete. If you have scratched through the melamine coating of the
rotator during installation, you may wish to apply several coats of clear acrylic spray to help
protect the bare metal from corrosion.
After installation is complete, test the system by operating the rotator through the entire
range of its rotation. It is helpful to do so with the help of an observer, so that rotation can be
stopped if some obstruction, binding, or tension on the coaxial cable’s turning loop should
be encountered during the performance test.
Installation Note
If using a roof tower with a long mast between the top of the tower and the antenna, the use of
a “Guy Bearing” is highly recommended. The Yaesu GS-050 and GS-065 include guying “ears”,
which allow attachment of guy cables. As installing a guying system may cause the center-lines
of the guy bearing and the rotator to become mis-aligned, be certain to check the roof tower at-
tachment and guy cable alignment to ensure that the mast is straight.
