Yaesu G-450ADC User Manual

7
20 mm
8.6 ～ 10.5 mm
4 mm
Crimp with crimping tool or a pair of pliers
Insert to the fullest extent
Assembly of 6-pin Plastic Connector
Tin the wires with solder
Make sure to insert the
Water Resist Boot first
2
5 3
6
345
12
7
4
Terminal 1, 6 and 7 are not used.
Assembly of 7-pin Metal Connector
Pin # 1 and 7 of the seven pin metal connector is not used.
(as viewed from pin insertion side) (as viewed from solder side)
Wiring for the control cable (identical numbers to be connected)
