Yaesu G-450ADC User Manual

Packing List (Check Before Installing Rotator)
Rotor ....................................................... 1
Controller ................................................1
Mast Clamps...........................................2
Plate (G-450CDC only)...........................2
U bolts ....................................................2
M8 x 16 Bolts ..........................................4
Hex. Nuts ................................................ 4
Spring Washers ......................................8
Flat Washers ..........................................4
7-pin Round Plug ....................................1
6-pin Rectangula Plug (with ) ........... 1 set
Rubber Boot ...........................................1
User Manual ...........................................1
Specications
Rotation Torque: 600 kgf-cm (43 ft-lbs.) (@ AC 117 V: G-450ADC)
600 kgf-cm (43 ft-lbs.) (@ AC 230 V: G-450CDC)
Braking Torque: 3000 kgf-cm (217 ft-lbs.)
Maximum Vertical load: Continuous load 100 kg or less
Instantaneous load 300 kg
Mast Outside Diameter:
φ
32 to
φ
63 (center protrudes by
φ
48 to
φ
52)
Rotation Range: 450°
360° Rotation Time (approx.): 56 seconds (± 20%)
Antenna K Coefcient: 100
Wind Loading Area: Pole type 0.5 m
2
x 0.5 m
Tower type 1 m
2
Maximum Continuous Duty: 3 minutes
Rotor Dimensions and Weight:
φ
186 x 263 mm, approx. 3.2 kg
Controller Dimensions: 190 (W) x 125 (H) x 150(D) mm
Controller Weight (approx.): 2.5 kg (G-450ADC)
2.7 kg (G-450CDC)
Power Supply Voltage: 117 VAC (G-450ADC)
230 VAC (G-450CDC)
Motor voltage (approx.): 20 VDC
