page 33MARK-V FT-1000MP Operating Manual
10.PKT
This control adjusts the tuning meter segment indi-
cations for Packet center tuning.
11. RTTY
This control adjusts the tuning meter segment indi-
cations for RTTY center tuning.
12.CW
This control adjusts the tuning meter segment indi-
cations for CW center tuning. It should be adjusted
such that the center segment lights up when your fa-
vorite pitch (as set by the CW PITCH control and con-
firmed by pressing the
[
SPOT
]
button) is received.
Additional Note
The volume of the beep that sounds when a front-
panel button is pushed can be adjusted by turning
a trimmer accessed via the small hole on the bot-
tom cover of the transceiver. Insert a small, thin,
insulated, flat screwdriver into the hole to adjust
VR3001 for the desired beep volume. The Beep
tone frequency is adjusted via
menu selection 4-2
;
see page 101.

Yaesu Mark-V FT-1000MP Specifications

General

Modes	SSB, CW, AM, FM, FSK
Receiver Type	Triple Conversion Superheterodyne
Audio Output	2.5 W into 4 ohms
Antenna Impedance	50 ohms
Receiver Sensitivity	0.16 μV for 10 dB S/N
Image Rejection	70 dB
IF Bandwidth	500 Hz (CW)
Power Supply Requirement	13.8 VDC ±10%
IF Rejection	>70 dB
