Yale GP100VX User Manual

Table 2. Weight of Counterweights
Model Weight
GLC40VX (GC/GLC080VX) 2249 kg (4958 lb)
GLC45VX (GC/GLC100VX) 2552 kg (5626 lb)
GLC/GDC55VX (GC/GLC120VX) 3170 kg (6988 lb)
GC/GLC080VXBCS 2149 kg (4738 lb)
GLC55SVX (GC/GLC100VXBCS, GC/GLC120SVX) 3205 kg (7066 lb)
(GC/GLC120VXPRS) 3773 kg (8318 lb)
GLP/GDP40VX5 (GP/GLP/GDP080VX) 2172 kg (4788 lb)
GLP/GDP40VX6 2370 kg (5225 lb)
GLP/GDP45SVX5 (GP/GLP/GDP090VX) 2504 kg (5520 lb)
GLP/GDP45VX6 (GP/GLP/GDP100VX) 2709 kg (5972 lb)
GLP/GDP50VX (GP/GLP/GDP100VX) 3009 kg (6634 lb)
GLP/GDP55VX (GP/GLP/GDP120VX) 3294 kg (7262 lb)
INSTALL
1. Make sure seals are on counterweight.
See Figure 15for lift truck models
• GLC40, 45, 55VX; GLC55SVX; (GLC080,
100, 120VX; GLC080, 100VXBCS;
GLC120SVX; GLC120VXPRS) (E818,
F818)
• GLP40VX5/VX6; GLP45SVX5, GLP45VX6;
GLP50-55VX (GLP080, 90, 100, 110,
120VX) (F813, G813, H813)
See Figure 16 for lift truck models
• GLC55SVX (GC/GLC80XVBCS, GC/
GLC100VXBCS; GC/GLC120SVX; AND
GC/GLC120VXPRS) (E818, F818)
See Figure 17 for lift truck models
• GLP40VX5/VX6; GLP45SVX5, GLP45VX6;
GLP50-55VX (GLP080, 90, 100, 110,
120VX) ( J813 )
2. Use a crane to install counterweight on lift truck.
When counterweight is installed, make sure
hooks on frame fully engage counterweight so it is
aligned with parts of frame. Install and tighten
capscrew to 1020 N•m (750 lbf ft).
3. Install tow pin and roll pin, if equipped. See sec-
tion Tow Pin for procedures.
4. If lift truck has an LPG fuel system, see one of the
following Service Manuals to install LPG tank
and bracket, after counterweight has been instal-
led.
LPG Fuel System, GM 4.3L Engine With GFI 900
YRM 1242 for lift truck models
• GLC40, 45, 55VX; GLC55SVX; (GLC080,
100, 120VX; GLC080, 100VXBCS;
GLC120SVX; GLC120VXPRS) (E818)
• GLP40VX5/VX6; GLP45SVX5, GLP45VX6;
GLP50-55VX (GLP080, 90, 100, 110,
120VX) (F813, G813)
LPG Fuel System, GM 4.3L Engine With PSI 900
YRM 1556 for lift truck models
• GLC40, 45, 55VX; GLC55SVX; (GLC080,
100, 120VX; GLC080, 100VXBCS;
GLC120SVX; GLC120VXPRS) (E818,
F818)
• GLP40VX5/VX6; GLP45SVX5, GLP45VX6;
GLP50-55VX (GLP080, 90, 100, 110,
120VX) ( G813, H813, J813 )
5. If lift truck is equipped with an overhead exhaust
system, install overhead exhaust pipe. See sec-
tion Exhaust System Repair for procedures.
Counterweight Replacement 0100 YRM 1243
20
