PERIODIC MAINTENANCE AND MINOR REPAIR
6-35
6
7. Tighten the axle nut, the final gear
case bolts and the brake torque
rod nuts to the specified torques.
8. Adjust the brake pedal free play.
(See page 6-19.)
WARNING
EWA10660
After adjusting the brake pedal free
play, check the operation of the
brake light.
EAU25850
Troubleshooting
Although Yamaha motorcycles receive
a thorough inspection before shipment
from the factory, trouble may occur dur-
ing operation. Any problem in the fuel,
compression, or ignition systems, for
example, can cause poor starting and
loss of power.
The following troubleshooting chart
represents a quick and easy procedure
for checking these vital systems your-
self. However, should your motorcycle
require any repair, take it to a Yamaha
dealer, whose skilled technicians have
the necessary tools, experience, and
know-how to service the motorcycle
properly.
Use only genuine Yamaha replace-
ment parts. Imitation parts may look like
Yamaha parts, but they are often inferi-
or, have a shorter service life and can
lead to expensive repair bills.
Tightening torques:
Axle nut:
92 Nm (9.2 m·kgf, 67 ft·lbf)
Final gear case bolt:
74 Nm (7.4 m·kgf, 54 ft·lbf)
Brake torque rod nut:
20 Nm (2.0 m·kgf, 14 ft·lbf)
U5SC21E0.book Page 35 Wednesday, May 19, 2004 11:41 AM
