60C5D11
4-4
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Fuel pump 1
2 Body 1
3 Fuel filter element 1
4Float 1
5 O-ring 1
Not reusable
2
×
36.2 mm
6 Fuel filter cup 1
7 Clip 9
8 Fuel joint 3
9Bolt 2 M6
×
12 mm
10 Washer 2
11 Clamp 2
12 Clamp 1
13 Fuel hose 2 Fuel joint-to-fuel joint
14 Fuel hose 1 Fuel pump-to-fuel joint
15 Plastic tie 2
Not reusable
16 O-ring 1
Not reusable
17 Bolt 2 M6
×
30 mm
18 Fuel hose 1 Fuel pump-to-fuel filter
12.5
×
300 mm
19 Plastic tie 2
Not reusable
20 Bolt 1 M6
×
16 mm
21 Bracket 1
22 Nut 1
23 Fuel hose 1 Fuel filter-to-fuel joint
12.5
×
950 mm
24 Plate 1
25 Bolt 1 M6
×
25 mm
26 Bolt 2 M6
×
25 mm
27 Grommet retaining plate 1
28 Plastic tie 1
Not reusable
29 Fuel joint 1
Fuel line and fuel filter
