13
Basic components
EMU2579D
Main components
NOTE:
* May not be exactly as shown; also may not be included as standard equipment on all mod-
els.
F100B
EMU26180
Remote control
The remote control lever actuates both the
shifter and the throttle. The electrical switch-
es are mounted on the remote control box.
TRIP TIME BATT
Km/h
knot
mph
km
mile
SPEED
YAMAHA
set
mode
10
9
8
7
3
4
5
6
2
1
12
13
15
14
2
11
ZMU05071
1. Top cowling
2. Top cowling lock lever
3. Drain screw
4. Anti-cavitation plate
5. Trim tab (anode)
6. Propeller*
7. Cooling water inlet
8. Anode
9. Clamp bracket
10. Tilt support lever
11. Flushing device
12. Power trim and tilt switch
13. Remote control box (side mount type)*
14. Digital tachometer*
15. Digital speedometer
To Next Page
