Maintenance
60
the main switch to “” (off) and re-
move the key, and remove the cord
from the engine shut-off switch. Turn
off the battery cut-off switch if your
boat has one.
●
Do not use your hand to hold the pro-
peller when loosening or tightening the
propeller nut. Put a wood block be-
tween the anti-cavitation plate and the
propeller to prevent the propeller from
turning.
Checkpoints
●
Check each of the propeller blades for
wear, erosion from cavitation or ventila-
tion, or other damage.
●
Check the propeller shaft for damage.
●
Check the splines for wear or damage.
●
Check for fish line tangled around the pro-
peller shaft.
●
Check the propeller shaft oil seal for dam-
age.
EMU30661
Removing propeller
EMU29196
Spline models
1. Straighten the cotter pin and pull it out
using a pair of pliers.
2. Remove the propeller nut, washer, and
spacer (if equipped).
3. Remove the propeller, washer (if
equipped), and thrust washer.
ZMU04262
ZMU01897
1. Cotter pin
2. Propeller nut
3. Washer
4. Spacer
5. Propeller
6. Thrust washer
ZMU03842
1
2
3
4
5
6
