2-13
E
EMU01295
STEERING FRICTION ADJUSTING
LEVER
A friction device provides resistance to
steering movement. This is adjustable
according to operator preference.
WARNING
@
Do not overtighten the friction adjusting
lever. If there is too much resistance, it
may be difficult to steer, which could
result in an accident.
@
Resistance Lever
Increase Turn to port
Decrease Turn to starboard
EMU01297
TRIM ANGLE ADJUSTING ROD
The position of the trim angle adjusting rod
determines the minimum trim angle of the
outboard motor in relation to the transom.
