2-16
E
EMU00161
TOP COWLING LOCK LEVER
To remove the engine top cowling, pull up
the lock lever. Then lift off the cowling. When
replacing the cowling, check to be sure it fits
properly in the rubber seal. Then lock the
cowling again by moving the lever down-
ward.
EMU01701
FLUSHING DEVICE
This device
1
is used to clean the cooling
water passages of the motor using a garden
hose and tap water.
NOTE:
@
Refer to “CLEANING COOLING-WATER
PASSAGES” in Chapter 4 for instructions on
usage.
@
EMU01128
WARNING INDICATOR(S)
If the engine develops a condition monitored
by the warning system, an indicator will
come on. Refer to the “WARNING SYSTEM”
section for details.
1
Warning indicator(s)
