Instrument and control functions
3-15
3
EAU13076
Fuel tank cap
To open the fuel tank cap
Open the fuel tank cap lock cover, in-
sert the key into the lock, and then turn
it 1/4 turn clockwise. The lock will be
released and the fuel tank cap can be
opened.
To close the fuel tank cap
With the key still inserted in the lock,
push down the fuel tank cap. Turn the
key 1/4 turn counterclockwise, remove
it, and then close the lock cover.
TIP
The fuel tank cap cannot be closed un-
less the key is in the lock. In addition,
the key cannot be removed if the cap is
not properly closed and locked.
WARNING
EWA11092
Make sure that the fuel tank cap is
properly closed after filling fuel.
Leaking fuel is a fire hazard.
1. Front wheel sensor
2. Front wheel sensor rotor
1. Rear wheel sensor
2. Rear wheel sensor rotor
1
2
1
2
1. Fuel tank cap lock cover
2. Unlock.
1
2
UB4CE1E0.book Page 15 Friday, August 3, 2018 10:57 AM

Yamaha MT-07 2019 Specifications

General

Displacement	689cc
Bore x Stroke	80.0mm x 68.6mm
Compression Ratio	11.5:1
Maximum Power	55.0 kW (74.8 PS) @ 9, 000 rpm
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	6-speed
Final Drive	Chain
Front Suspension	Telescopic forks
Front Brake	Hydraulic dual disc, Ø282 mm
Rear Brake	Hydraulic single disc, Ø245 mm
Front Tire	120/70 ZR17 M/C(58W) (Tubeless)
Rear Tire	180/55 ZR17 M/C(73W) (Tubeless)
Overall Length	2, 085 mm
Overall Width	745 mm
Overall Height	1, 090 mm
Seat Height	805 mm
Wheelbase	1, 400 mm
Wet Weight	182 kg
Fuel Tank Capacity	14 L
Minimum Ground Clearance	140 mm
Oil Tank Capacity	3.0 L
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Maximum Torque	68.0 Nm (6.9 kgf-m) @ 6, 500 rpm
Rear Suspension	Swingarm, (link suspension)
