Yamaha MT-07 2019 User Manual

Periodic maintenance and adjustment
6-20
6
EAU37914
Checking the brake lever free
play
There should be no free play at the
brake lever end. If there is free play,
have a Yamaha dealer inspect the
brake system.
WARNING
EWA14212
A soft or spongy feeling in the brake
lever can indicate the presence of
air in the hydraulic system. If there is
air in the hydraulic system, have a
Yamaha dealer bleed the system be-
fore operating the vehicle. Air in the
hydraulic system will diminish the
braking performance, which may re-
sult in loss of control and an acci-
dent.
EAU36505
Brake light switches
The brake light should come on just
before braking takes effect. The brake
light is activated by switches connect-
ed to the brake lever and brake pedal.
Since the brake light switches are
components of the anti-lock brake sys-
tem, they should only be serviced by a
Yamaha dealer.
1. No brake lever free play
1
UB4CE1E0.book Page 20 Friday, August 3, 2018 10:57 AM

Yamaha MT-07 2019 Specifications

General

Displacement	689cc
Bore x Stroke	80.0mm x 68.6mm
Compression Ratio	11.5:1
Maximum Power	55.0 kW (74.8 PS) @ 9, 000 rpm
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	6-speed
Final Drive	Chain
Front Suspension	Telescopic forks
Front Brake	Hydraulic dual disc, Ø282 mm
Rear Brake	Hydraulic single disc, Ø245 mm
Front Tire	120/70 ZR17 M/C(58W) (Tubeless)
Rear Tire	180/55 ZR17 M/C(73W) (Tubeless)
Overall Length	2, 085 mm
Overall Width	745 mm
Overall Height	1, 090 mm
Seat Height	805 mm
Wheelbase	1, 400 mm
Wet Weight	182 kg
Fuel Tank Capacity	14 L
Minimum Ground Clearance	140 mm
Oil Tank Capacity	3.0 L
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Maximum Torque	68.0 Nm (6.9 kgf-m) @ 6, 500 rpm
Rear Suspension	Swingarm, (link suspension)
