Yamaha MT-07 2019 User Manual

Instrument and control functions
3-24
3
EAU85220
Luggage strap holders
Use the indicated strap points to se-
cure luggage to the vehicle.
To use the luggage strap holders under
the passenger seat, remove the pas-
senger seat (3-19), remove the straps
from their hooks, and then install the
seat with the straps hanging out.
EAU70641
Auxiliary DC connector
This vehicle is equipped with an auxil-
iary DC connector. Consult your
Yamaha dealer before installing any
accessories.
1. Luggage strap holder
2. Hook
1. Luggage strap holder
1
2
2
1
1
UB4CE1E0.book Page 24 Friday, August 3, 2018 10:57 AM

Yamaha MT-07 2019 Specifications

General

Displacement	689cc
Bore x Stroke	80.0mm x 68.6mm
Compression Ratio	11.5:1
Maximum Power	55.0 kW (74.8 PS) @ 9, 000 rpm
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	6-speed
Final Drive	Chain
Front Suspension	Telescopic forks
Front Brake	Hydraulic dual disc, Ø282 mm
Rear Brake	Hydraulic single disc, Ø245 mm
Front Tire	120/70 ZR17 M/C(58W) (Tubeless)
Rear Tire	180/55 ZR17 M/C(73W) (Tubeless)
Overall Length	2, 085 mm
Overall Width	745 mm
Overall Height	1, 090 mm
Seat Height	805 mm
Wheelbase	1, 400 mm
Wet Weight	182 kg
Fuel Tank Capacity	14 L
Minimum Ground Clearance	140 mm
Oil Tank Capacity	3.0 L
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Maximum Torque	68.0 Nm (6.9 kgf-m) @ 6, 500 rpm
Rear Suspension	Swingarm, (link suspension)
