Motorcycle care and storage
7-3
7
will become slippery, which
could cause loss of control.
Thoroughly clean the surfaces
of these parts before operating
the vehicle.
[EWA20650]
5. Treat rubber, vinyl, and unpainted
plastic parts with a suitable care
product.
6. Touch up minor paint damage
caused by stones, etc.
7. Wax all painted surfaces using a
non-abrasive wax or use a detail
spray for motorcycles.
8. When finished cleaning, start the
engine and let it idle for several
minutes to help dry any remaining
moisture.
9. If the headlight lens has fogged
up, start the engine and turn on
the headlight to help remove the
moisture.
10. Let the vehicle dry completely be-
fore storing or covering it.
NOTICE
ECA26320
Do not apply wax to rubber or
unpainted plastic parts.
Do not use abrasive polishing
compounds as they will wear
away the paint.
Apply sprays and wax sparingly.
Wipe off excess afterwards.
WARNING
EWA20660
Contaminants left on the brakes or
tires can cause loss of control.
Make sure there is no lubricant
or wax on the brakes or tires.
If necessary, wash the tires with
warm water and a mild deter-
gent.
If necessary, clean the brake
discs and pads with brake
cleaner or acetone.
Before riding at higher speeds,
test the vehicle’s braking per-
formance and cornering behav-
ior.
EAU83472
Storage
Always store the vehicle in a cool, dry
place. If necessary, protect it against
dust with a porous cover. Be sure the
engine and the exhaust system are
cool before covering the vehicle. If the
vehicle often sits for weeks at a time
between uses, the use of a quality fuel
stabilizer is recommended after each
fill-up.
NOTICE
ECA21170
Storing the vehicle in a poorly
ventilated room or covering it
with a tarp, while it is still wet,
will allow water and humidity to
seep in and cause rust.
To prevent corrosion, avoid
damp cellars, stables (because
of the presence of ammonia)
and areas where strong chemi-
cals are stored.
Long term storage
Before storing the vehicle long term (60
days or more):
UB4CE1E0.book Page 3 Friday, August 3, 2018 10:57 AM

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Yamaha MT-07 2019 and is the answer not in the manual?

Yamaha MT-07 2019 Specifications

General IconGeneral
Displacement689cc
Bore x Stroke80.0mm x 68.6mm
Compression Ratio11.5:1
Maximum Power55.0 kW (74.8 PS) @ 9, 000 rpm
Fuel SystemFuel Injection
Ignition SystemTCI
Transmission6-speed
Final DriveChain
Front SuspensionTelescopic forks
Front BrakeHydraulic dual disc, Ø282 mm
Rear BrakeHydraulic single disc, Ø245 mm
Front Tire120/70 ZR17 M/C(58W) (Tubeless)
Rear Tire180/55 ZR17 M/C(73W) (Tubeless)
Overall Length2, 085 mm
Overall Width745 mm
Overall Height1, 090 mm
Seat Height805 mm
Wheelbase1, 400 mm
Wet Weight182 kg
Fuel Tank Capacity14 L
Minimum Ground Clearance140 mm
Oil Tank Capacity3.0 L
Engine TypeLiquid-cooled, 4-stroke, DOHC, 4-valve
Maximum Torque68.0 Nm (6.9 kgf-m) @ 6, 500 rpm
Rear SuspensionSwingarm, (link suspension)
