Yamaha RX-V463 Service Manual

28
RX-V463/HTR-6140/DSP-AX463
RX-V463/HTR-6140/
DSP-AX463
Input level Volume
SPEAKER OUT SUBWOOFER
OUTPUT
A1.ANLOG BYPAS
• Details of Self-Diagnostic Function menu
A. BYPASS
Using the sub-menu, it is possible to select ANA-
LOG BYPASS output or DSP BYPASS output.
ANALOG BYPASS
The analog input sound signal is output to FRONT L/R
with EFFECT OFF.
INPUT: DVD ANALOG
SPEAKER OUT: 1 kHz, SUBWOOFER OUTPUT: 50 Hz
A2.DSP BYPASS
Both ch, -20 dBm +6.0 dB
FRONT
+11.5 dBm
CENTER
-∞
SURROUND
-∞ -∞
Input level Volume
SPEAKER OUT SUBWOOFER
OUTPUT
INPUT: DVD ANALOG
SPEAKER OUT: 1 kHz, SUBWOOFER OUTPUT: 50 Hz
Both ch, -20 dBm +6.0 dB
FRONT
+11.5 dBm
CENTER
-∞
SURROUND
-∞ -∞
DSP BYPASS
The digital input sound signal is output to FRONT L/R
with EFFECT OFF.
● ダイアグメニュー詳細
A. BYPASS
サブメニューによりANALOG BYPASS/DSP
BYPASSが選択可能です。
ANALOGBYPASS
アナログ入力の音声信号をEFFECTOFFでFRONTL/
Rへ出力します。
DSPBYPASS
デジタル入力の音声信号をEFFECTOFFでFRONTL/
Rへ出力します。
B. AUDIO CHECK
AUDIO CHECK
The input sound signal is output.
* When the inputted sound signal is 2 ch L/R, it is
distributed as follows when output.
L ch: FRONT L, CENTER, SURROUND L, LFE ( L
ch +10 dB)
R ch: SURROUND R
B1.AUDIO CHECK
Input level Volume
SPEAKER OUT SUBWOOFER
OUTPUT
INPUT: DVD ANALOG
SPEAKER OUT: 1 kHz, SUBWOOFER OUTPUT: 50 Hz
Both ch, -20 dBm +6.0 dB
FRONT
+11.5 dBm
CENTER
+11.5 dBm
SURROUND
+11.5 dBm 0 dBm
B. AUDIOCHECK
AUDIOCHECK
入力された音声信号を出力します。
※ 入力された音声信号が2chL/Rの場合は、下記の
ように振り分け出力します。
Lch：FRONTL、CENTER、SURROUNDL、LFE
（Lch+10dB）
Rch：SURROUNDR
B3.MUTE ALL
MUTE ALL
Sound signals of all channels are muted by System IC
(MAIN P.C.B.) and Transistor (Q5008-5011 MAIN
P.C.B.).
B2.ANALOG PLAY
ANALOGAUDIOPLAYBACK
アナログ入力された音声信号を出力します。
MUTEALL
全チャンネルの音声信号をシステムIC（MAINP.C.B.）
およびトランジスタ（Q5008-5011MAINP.C.B.）で
ミュートします。
ANALOG AUDIO PLAYBACK
The analog input sound signal is output.
