Yamaha RX-V463 Service Manual

34
RX-V463/HTR-6140/DSP-AX463
RX-V463/HTR-6140/
DSP-AX463
H1.1k - 1dB/44
1 kHz, -1 dB / 44.1 kHz
The test tone (1 kHz, -1 dB / 44.1 kHz) is output.
1 kHz, -61 dB / 44.1 kHz
The test tone (1 kHz, -61 dB / 44.1 kHz) is output.
Mute / 44.1 kHz
No signal is output.
XM tone / 44.1 kHz
The XM tone / 44.1 kHz is output.
ISO tone / 44.1 kHz
The ISO tone /44.1 kHz is output.
1 kHz, -1 dB / 32.0 kHz
The test tone (1 kHz, -1 dB / 32.0 kHz) is output.
1 kHz, -61 dB / 32.0 kHz
The test tone (1 kHz, -61 dB / 32.0 kHz) is output.
Mute / 32.0 kHz
No signal is output.
XM tone / 32.0 kHz
The XM tone / 32.0 kHz is output.
ISO tone / 32.0 kHz
The ISO tone / 32.0 kHz is output.
XM bus power: OFF
The power of XM module is turned off.
H3.MUTE /44
H4.XM TONE /44
H5.ISO TONE/44
H6.1k - 1dB/32
H7.1k -61dB/32
H8.MUTE /32
H9.XM TONE /32
H10.ISOTONE/32
H11.BUSPWR:OFF
H. XM STATUS (U, C models)
The output check of XM radio is executed.
(Connect XM radio antenna module to this unit
before executing.)
H2.1k -61dB/44
H. XMSTATUS
このモデルには適用されません。

Yamaha RX-V463 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
RMS rated power	525 W
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.06 %
Equalizer	Yes
Product color	Silver
AM band range	87.5 - 108 kHz
FM band range	530 - 1710 MHz
Supported radio bands	AM, FM
Dimensions (WxDxH)	435 x 171 x 352 mm
Power consumption (typical)	440 W

Weight and Dimensions

Weight	8500 g
