Yamaha YZ250 User Manual

1-8
SPECIAL TOOLS
GEN
INFO
Part number Tool name / How to use IIIustration
YU-33975, 90890-01403 Ring nut wrench YU-33975 90890-01403
This tool is used when tighten the steering ring nut
to specification.
YM-01442, 90890-01442 Fork seal driver
YM-01442 90890-01442
This tool is used when install the fork oil seal.
YM-01500, 90890-01500 Cap bolt wrench YM-01500 90890-01500
This tool is used to loosen or tighten the base valve.
YM-01501, 90890-01501 Cap bolt ring wrench
YM-01501 90890-01501
This tool is used to loosen or tighten the damper
assembly.
YU-3112-C, 90890-03112 Yamaha pocket tester YM-3112-C 90890-03112
Use this tool to inspect the coil resistance,
output voltage and amperage.
YU-8036-B Inductive tachometer
YU-8036-B 90890-03113
90890-03113 Engine tachometer
This tool is needed for observing engine rpm.
YM-91042, 90890-04086 Clutch holding tool
YM-91042 90890-04086
This tool is used to hold the clutch when removing
or installing the clutch boss securing nut.
YM-34487 Dynamic spark tester YM-34487 90890-06754
90890-06754 Ignition checker
This instrument is necessary for checking the igni-
tion system components.
ACC-QUICK-GS-KT Quick gasket
®
ACC-QUICK-GS-KT 90890-85505
90890-85505 YAMAHA Bond No. 1215
This sealant (Bond) is used for crankcase mating
surface, etc.
1P8-9-30-1 19/5/04 9:00 AM Page 15

Yamaha YZ250 Specifications

General

Engine Type	249cc liquid-cooled 2-stroke; reed-valve inducted
Bore x Stroke	66.4mm x 72.0mm
Compression Ratio	8.9~10.6:1
Ignition	CDI
Transmission	5-speed; multiplate wet clutch
Final Drive	Chain
Suspension Rear	KYB® single shock; fully adjustable, 12.4-in travel
Brakes Front	Hydraulic disc, 270mm
Brakes Rear	Hydraulic disc, 240mm
Tires Front	80/100-21
Tires Rear	110/90-19
Length	85.8 in
Width	32.5 in
Wheelbase	58.5 in
Ground Clearance	14.2 in
Fuel Capacity	2.1 gal
Wet Weight	227 lb
Suspension Front	KYB® inverted fork; fully adjustable, 11.8-in travel
Fuel Delivery	Keihin PWK38S carburetor
