Yamato DE411 - Accessory Options (Factory Required)

63
12. WIRING DIAGRAM
Wiring Diagram Glossary
Symbol
Component
Symbol
Component
ELB1
Earth Leakage Breaker (ELB)
PI1
Photo coupler
T1
Wiring terminal 1
DS1
Door switch
T2
Wiring terminal 2
CR1
Spark eliminator
X1
Main relay
FM1
Fan motor
X2
Thermal relay
PLB
Type V planar board
X3
Phase reversal relay
PIO
Type V display board
SSR1, 2
Solid state relay
OH1
Independent Overheat Prevention
Device
H1, 2, 3
Heaters
TH1-1
Independent Overheat Prevention
Device sensor
CT1, 2, 3
Current sensing element
TH1-2
Temperature control sensor
TF
Transformer
TF2
Transformer
Optional portion
Symbol
Component
Symbol
Component
ELB101
Earth Leakage Breaker (w/wire
lead)
OPB
Type V option board
ES101
Emergency stop button
T103
Auto damper terminal block
T101
External output terminal block
DM101
Auto damper motor
T102
External output terminal block
LS101､102
Auto damper limit switch
GR101
Data logger
SSR101､
102
Auto damper solid state relay
SW101
Data logger switch
VR101
Auto damper volume resistor
