Revision History
Revision History
The revision dates and numbers of the revised catalogs are given on the bottom of the back cover.
Date of
printing
Date of original
publication
Revision number
Date of Printing
July 2004
Rev. No.
–
Section
–
Revised Content
First edition:
Based on the Japanese version of the JUNMA
Series catalog printed in July 2004.
(Catalog No.: KAJP S800000 23A)
July 2005 –
All chapters
All chapters
P4: Connection to Peripheral
Devices
P4: SERVOPACKs and Applicable
Servomotors
P5: Cable and Connectors
P8: Speed/Torque Characteristics
P10: Ratings and Specifications
P12: Reference Filter Setting (FIL)
P14: Connection Diagram
P17: Wiring Precautions
P18: Explanation of I/O Signals
P19: Connection Example of Input
Signal
P19: Connection Example of Output
Signal
P30: External Fuse
P34: Contact Information
Second edition:
Based on the Japanese version of the JUNMA
Series catalog printed in February 2005.
(Catalog No.: KAJP S800000 23B)
Revision: Exterior of SERVOPACK and
servomotor.
Addition: Contact information in China.
(Cables and peripheral devices)
Addition: Cautions and Warnings.
Revision: Drawings in the system configuration.
Revised.
Revised.
Revision: Repetitive operating range.
Revision: Power loss at rated output.
Revision: Acceleration/Deceleration Time for
Step Reference.
Revised.
Revised.
Addition: Notes on the lag time for the alarm
signal and the phase-C output signal.
Revision: Connection diagrams.
Added.
Added.
Added.
Printed in Japan July 2005 04-7©
LITERATURE NO. KAEP S800000 23B
