Yealink SIP-T40G Configuration Guide

BROADSOFT PARTNER CONFIGURATION GUIDE – YEALINK T4X IP PHONE 20-BD5476-00
©
2017 BROADSOFT INC. PAGE 40 OF 150
Figure 23 Xtended Services Platform Configuration
4.4.1 BroadWorks User Service Configuration
Integration with the BroadWorks Xtended Services Interface for User Service
Configuration enables the phone to display and configure BroadWorks user services, such
as Remote Office, BroadWorks Anywhere, Call Forwarding, and Simultaneous Ring. To
enable User Service Configuration, perform the following steps.
Step Command Purpose
Step 1 bw.xsi.enable =
Example:
bw.xsi.enable = 1
Enable XSI feature.
 0 for Disabled
 1 for Enable
Step 2 sip.authentication_for_xsi =
Example:
sip.authentication_for_xsi = 1
Enable the Xsp authentication
mode.
 0= BroadWorks User Login
credentials
 1= SIP Authentication
credentials
Step 3 account.1.xsi.user=
account.1.xsi.password =
Example:
account.1.xsi.user= 2405551111
account.1.xsi.password = 123456
Set the Xsi login user name
and password for line 1.
Step 4 account.1.xsi.host =
Example:
account.1.xsi.host =xsp1.iop1.broadworks.net
Set the IP address or domain
name of the Xsp server.

Yealink SIP-T40G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Wall mountable	Yes
Wi-Fi	No
Security algorithms	AES, HTTPS, SSL/TLS
Networking standards	IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP, TFTP, HTTP, HTTPS
Voice codecs	G.711, G.711a, G.711u, G.722, G.726, G.729ab
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	0.6 A
AC adapter output voltage	5 V
Power consumption (typical)	1.6 W
Certification	CE, FCC, ISO 9001
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Volume control	Digital
Display diagonal	2.3 \
Display resolution	132 x 64 pixels
Lines quantity	3 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	175 mm
Width	212 mm
Height	54 mm
