Yealink SIP-T52S Administrator's Guide

Configuring Basic Features
283
In this example, a system logo (Yealink logo) is displayed on the image logo screen:
Logo is not applicable to SIP-T54S/T52S/T48G/T48S/T46G/T46S/T29G IP phones. These IP
phone models use wallpaper instead. For more information on wallpaper, refer to Wallpaper on
page 182.
The following table lists the supported logo file format and resolution for each phone model.
Phone Model
Logo File
Format
Resolution
SIP-T42G/T42S/T41P/T41S/CP860
.dob
<=192*64 2 gray scale
SIP-T27P/G
.dob
<=240*120 2 gray scale
SIP-T40P/T40G/T23P/T23G/T21(P) E2/
T19(P) E2
.dob
<=132*64 2 gray scale
CP920
.dob
<=248*120 2 gray scale
Note
Customizing a Logo Template File
The common picture format can be *.bmp. Yealink IP phones only support the *.dob format
logo files. Yealink provides PictureExDemo tool to convert *.bmp format to *.dob format. You
can ask the distributor or Yealink FAE for the PictureExDemo tool.
Before uploading your custom logo to IP phones, ensure your logo file is correctly formatted.

Yealink SIP-T52S Specifications

General

Touchscreen	-
Display diagonal	2.8 \
Backlight display	Yes
Display resolution	320 x 240 pixels
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
AC adapter input voltage	100 - 240 V
Bluetooth version	2.1+EDR
Security algorithms	802.1x RADIUS, HTTPS, MD5
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	G.722, G.723, G.723.1, G.726, OPUS, iLBC
Volume control	Digital
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Front camera	No
Operating system installed	Linux

Weight and Dimensions

Depth	212 mm
Width	211.6 mm
Height	166.8 mm
