Yealink SIP-T53W Auto Provisioning Guide

Yealink IP Phones Auto Provisioning Guide
12
An Instance of Auto Provision Configuration
This section shows an instance of auto provision configuration.
1. Manage boot files.
Specify the desired URL (e.g., tftp://10.2.5.193/network.cfg) of the configuration files in the
boot file (e.g., y000000000000.boot). For more information, refer to Managing Boot Files.
2. Manage configuration files.
Add/Edit the desired configuration parameters in the CFG file (e.g., features.cfg) you want
the IP phone to download. For more information on how to manage configuration files,
refer to Managing Configuration Files.
3. Configure the TFTP server.
1) Place boot files, configuration files and resource files to TFTP root directory (e.g.,
D:\TFTP Directory).

Yealink SIP-T53W Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP mobile phone
Product color	Gray
Keypad illumination	Yes
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Security algorithms	AES, HTTPS, SIPS
Networking standards	IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Lines quantity	8 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.3 W
Volume control	Buttons
Number of programmable keys	8
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Number of DECT wireless handsets	4
Voice codecs	G.722, G.723.1, G.726, G.729A, G.729B, OPUS, iLBC

Weight and Dimensions

Depth	210.6 mm
Width	212 mm
Height	174.5 mm
